Product
Description
Permaloc
StructurEdge is a flexible L-shaped aluminum paving restraint designed
as an edge restraint for:
- Patios
- Walkways
- Driveways
- Entryways
- Cartpaths
- Other
paver installations
Available
in heavy, medium and light duty grades in 1-5/8” and 2-1/4”
heights for all commercial, design-build, and residential jobs.
Aluminum
will not rust, rot, or crack and is excellent choice for marine
environments.
StructurEdge
provides a clean, unobstructed edge along the paver installation
allowing the use of a power edger directly adjacent to the paving
stones.
StructurEdge
readily forms to curves, radii and angles allowing wide installation
flexibility.
Anchoring
is accomplished through the use of 10" spiral steel spikes
and is designed to receive spikes every 6".
The
interlocking sliding connectors eliminate possible weak points
and unlike bulky triangular restraints, the tight fitting "L-shaped"
design promotes healthy grass and accommodates irrigation heads.
Product
Background
StructurEdge
is designed for the areas where hardform and natural landscape
meet. Designers tell us that these areas are the most difficult
to retain, although well defined on paper, their clarity is often
lost to the realities of time and ongoing maintenance.
Architects
and Engineers requested that we design a more effective alternative
to the Plastic, P.V.C. and steel systems currently on the market.
The most common situation that the specifiers raised about the other
systems was they were damaged easily by maintenance equipment, separated
at the joints and were just not designed to last the lifetime of
the installation.
StructurEdge
is a permanent paving restraint system that is designed to be
easier to install and out-perform plastic, P.V.C. and steel systems.
We are confident that Permaloc StructurEdge will exceed your performance
expectations.
Design
Features
Permaloc
StructurEdge offers many unique features:
- Reversible
design allows the base to be installed under or away from the
paver
- Strong
"L-shaped" design
- Designed
for both straight and curvilinear applications
- Convenient
8'-0" UPS-able sections
- 8'-0"
sections readily form diameters as small as 3'-0"
- Secure
anchoring with 10" spikes
- Easily
maintained with power landscape edgers
- Easy
to install
- Aluminum
eliminates cracking, rusting or rotting
- Safe
and aesthetic
- Rapid
permanent installation
Product
Applications
3/32"
x 1-5/8" (2.4mm x 41mm) Our light duty restraint designed
for residential patio and walkway applications.
1/8"
x 1-5/8" (3.2mm x 41mm) Our medium duty 6cm paver restraint
used for patios, walkways and driveways.
3/16"
x 1-5/8" (4.8mm x 41mm) Our heavy duty 6cm paver restraint
used for driveways and walkways.
1/8"
x 2-1/4" (3.2mm x 57mm) Our light duty 8cm paver restraint.
3/16"
x 2-1/4" (4.8mm x 57mm) Our heavy duty 8cm paver restraint.
Product
Sizes and Finishes
(A)
Sizes:
3/32"
x 1-5/8" x 8'-0"
1/8" x 1-5/8" x 8'-0"
3/16" x 1-5/8" x 8'-0"
1/8" x 2-1/4" x 8'-0"
3/16" x 2-1/4" x 8'-0" |
(2.4mm
x 41mm x 2.44m)
(3.2mm x 41mm x 2.44m)
(4.8mm x 41mm x 2.44m)
(3.2mm x 57mm x 2.44m)
(4.8mm x 57mm x 2.44m) |
(B)
Finishes
Mill
Finish
Black DuraFlex |
(Natural
Aluminum)
(Electrostatically applied baked on acrylic paint) |
Other
Products Offered
CleanLine
– (Specification grade)
Aluminum Landscape Edging, CSI - 02945
ProLine
- (Design Build grade)
Aluminum Landscape Edging, CSI - 02945
PermaStrip
– L-shaped Aluminum Maintenance Strip, CSI - 02945
AsphaltEdge
- L-shaped Aluminum Asphalt Restraint, CSI – 02760
AthletEdge
/ TR – L-shaped Aluminum Track Restraint CSI - 02760
AthletEdge
/ CT – L-shaped Aluminum Court Restraint CSI - 02760
"Permaloc" and "StructurEdge" are trademarks
of Permaloc Corporation. Patent #5301461. Other patents pending.
|
