Product Description

Tired of broken edges and high maintenance costs on athletic surfaces?

The AthletEdge family of products is the first restraint system in the world to be designed to perform integrally with asphalt and sport surfacing.

AthletEdge.tr (track surfacing restraint) and AthletEdge.ct (court surface restraint) are engineered to edge surfaces over aggregate, asphalt and concrete.

Applications include tracks, basketball and tennis courts, jogging and walking trails and numerous other projects.

Product Background

AthletEdge.tr (track surfacing restraint) and AthletEdge.ct (court surface restraint) are the first restraint products specifically engineered to be installed and perform integrally with sports surfacing/asphalt installations.

Permaloc AthletEdge is a line of flexible, L-shaped aluminum sporting surface/asphalt restraints designed for use over: aggregate, asphalt and concrete. From running tracks to tennis courts, AthletEdge provides a clean appearance on your sports installations.

AthletEdge's patented design and installation features work in concert with your sports surfacing allowing a clean maintainable edge on your sports installations for years to come.

Design Features

Permaloc AthletEdge offers these unique features:

• AthletEdge has numerous patented features.

• Wall heights include 1", 1-1/2", 2", 2-1/2", 3" & 4".

• Side wall “weep holes” aid lateral drainage.

• Finishes include Mill Finish and Black DuraFlex (painted).

• A unique sliding connection system provides a continuous installation.

Product Sizes and Finishes

(A) Sizes: AthletEdge.tr is available in vertical wall heights of:

(A) - Sizes: AthletEdge.ct is available in vertical wall heights of:

(B) Finishes

*Refer to Permaloc's current Installation Guidelines and Warranty Information.

Anchoring Options Include: Aggregate Spikes manually driven; Overlay Spikes or nails manually driven or QuickDrive 2000 screw system; Over Concrete – Ramset Trackfast System. Length of anchor and spacing may vary with base material and installation method.

Other Products Offered

ProLine - (Design Build grade)
Aluminum Landscape Edging, CSI - 02945

CleanLine– (Specification grade) Aluminum Landscape Edging, CSI - 02945

StructurEdge - L-shaped Aluminum Paver Restraint, CSI -02760

PermaStrip – L-shaped Aluminum Maintenance Strip, CSI - 02945

AsphaltEdge - L-shaped Aluminum Asphalt Restraint, CSI -02760

“Permaloc” and “AthletEdge” are trademarks of Permaloc Corporation. Patent #5301461. Other patents pending.
